TCLAD Immersion Cooling Fluids (ICFs)

TCLAD’s proprietary immersion cooling fluids provide an efficient, cost-effective and environmentally sustainable solution for managing high thermal loads in power–dense electronic systems. These advanced ester-based dielectric fluids are non-toxic, non-corrosive, and engineered for long-term operational reliability in mission-critical applications where sustainability is a priority.

By fully submerging heat-generating components in a thermally conductive, electrically insulating dielectric fluid, heat is removed directly at the source. As the fluid absorbs thermal energy, it becomes less dense and rises, creating a passive convection loop that circulates the fluid without pumps or moving parts. For applications requiring enhanced heat transfer, pumps can be added to accelerate fluid movement and cooling.

Due to their lower viscosity and higher density, TCLAD’s ester-based immersion fluids outperform traditional alternatives such as mineral oil, polyalphaolefin (POA), perfluorocarbon (PFC), and silicon oil — offering superior thermal performance and environmental benefits in a single solution.
